Description

Specifications:

Material:
• Solid Silica Gel
Finish:
• Clear, UV inhibitor infused to prevent yellowing or caking.
Socket Type:
• T5 Wedge base or S8 Wedge base
Pin gap width:
• T5: 5.5 Millimeters
• S8: 12.6 Millimeters
Dimensions:
• LV1-T5WDG: .5” W x 1.2” H
• LV2-T5WDG: .5” W x 1.2” H
• LV2-S8WDG: .9” W x 1.7” H
Voltage Range:
• 12-15 volts AC/DC
IP Rating:
• IP 65
• Made for use in enclosed fixtures.
Electrical:
• LV1-T5WDG: 120 Lumens, 1.5 Watts, .13 VA, .7 PF
• LV2-T5WDG: 170 Lumens, 2.5 Watts, .17 VA, .7 PF
• LV2-S8WDG: 170 Lumens, 2.5 Watts, .17 VA, .7 PF
Rated Hours:
• 25,000
Dimmable:
• Yes with secondary side dimmer.
Certification:
• CETL listed and approved.
• FCC Certified (won’t interfere with electronics)
