Description

CL-233 Well Light

HOUSING: Cast brass adjustable fixture, suspended inside a reversible PVC sleeve with both flat and angle-cut options on either end. FINISH: AB-Antique Bronze Natural toning process. AB finish will vary due to the artistic process. SS-Stainless Steel. (The stainless steel grade is 316) LENS: Clear, tempered, and heat resistant convex glass. Extra flat lens included SOCKET: Top grade ceramic bi-pin socket with retention clip. LAMP: 12V, MR-15 halogen, 50W max. L-BAB-C20 (20w) standard. See below for available LED lamps.

GASKET: Silicone “O” ring seals faceplate to housing providing weather tight protection WIRING: Fixture is prewired with a 3-ft 18-2 SJT-W direct cord. Wire Connector available separately. Gel filled wire nut CX-854 may be ordered from Corona Lighting. MOUNTING: In-ground direct burial or concrete encasement.

A remote 12 Volt transformer is required. See transformers and accessories for a variety of options and choices. Voltage range for halogen lamps: 11V-12.5V Voltage range for LED lamps: 9V-17V

View/Download Printable Specification Sheet View/Download Printable Assembly/Installation Instructions

WARRANTY: Limited lifetime warranty on brass fixtures against manufacturer’s defects.
